Switch Toggle ON OFF ON SPDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Threads
Miniature Toggle Switch
立创商城:
7103SCWCQE
艾睿:
Switch Toggle ON OFF ON SPDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Threads
Allied Electronics:
Switch Toggle ON OFF ON SPDT Round Lever PC Pins 5
Chip1Stop:
Switch Toggle ON OFF ON SPDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Threads
Verical:
Switch Toggle ON OFF ON SPDT Round Lever PC Pins 5A 250VAC 28VDC PC Mount with Threads Medical Bulk
Newark:
# C & K COMPONENTS 7103SCWCQE Toggle Switch,RIGHT ANGLE,SPDT,ON-OFF-ON,PC TAIL Terminal,TOGGLE BAT,PCB Hole Count:3
MASTER:
Miniature Toggle Switch
Online Components:
Miniature Toggle Switch
Electro Sonic:
Miniature Toggle Switch
额定电流 5.00 A
排数 1
触点类型 SPDT
额定电流Max 5A @120VAC, 28VDC
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压DC Max 28 V
额定电压AC Max 250 V
接触电阻Max <10 mΩ
安装方式 Through Hole
封装 -
长度 12.7 mm
高度 30.61 mm
封装 -
触点材质 Coin Silver
工作温度 -30℃ ~ 85℃
产品生命周期 40000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509065
