74AHCT1G00DCKRE4

单路2输入正与非门 SINGLE 2-INPUT POSITIVE-NAND GATE

Operating Range of 4.5 V to 5.5 V

Max tpd of 7.1 ns at 5 V

Low Power Consumption, 10-µA Max ICC

±8-mA Output Drive at 5 V

Inputs Are TTL-Voltage Compatible

Latch-Up Performance Exceeds 250 mA Per JESD 17

ESD Protection Exceeds JESD 22

– 2000-V Human-Body Model A114-A

– 200-V Machine Model A115-A

– 1000-V Charged-Device Model C101

得捷:
IC GATE NAND 1CH 2-INP SC70-5

艾睿:
NAND Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R

安富利:
NAND Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R

Chip1Stop:
NAND Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R

Verical:
NAND Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R

Win Source:
IC GATE NAND 1CH 2-INP SC-70-5
