74AHC1G125DBVTG4

具有三态输出单总线缓冲器门 SINGLE BUS BUFFER GATE WITH 3-STATE OUTPUT

Description

The SN74AHC1G125 device is a single bus buffer gate/line driver with 3-state output. The output is disabled when the output-enable OE input is high. When OE is low, true data is passed from the A input to the Y output.

Features

• Operating Range of 2 V to 5.5 V

• Max tpd of 6 ns at 5 V

• Low Power Consumption, 10-µA Max ICC

• ±8-mA Output Drive at 5 V

Applications

• Projectors

• TVs

• Servers

• Motor Controls: AC Induction

• Patient Monitoring

• Electronic Points of Sale
