16位寄存器 16-Bit Registers
Flip Flop 2 Element D-Type 8 Bit Positive Edge 48-BSSOP 0.295", 7.50mm Width
得捷:
IC FF D-TYPE DUAL 8BIT 48SSOP
立创商城:
74FCT162374CTPVCT
艾睿:
Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP T/R
安富利:
Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP T/R
Chip1Stop:
Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP T/R
Verical:
Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP T/R
罗切斯特:
Flip Flop D-Type Bus Interface Pos-Edge 3-ST 2-Element 48-Pin SSOP T/R
DeviceMart:
IC 16BIT REGISTERS 48SSOP
德州仪器TI:
16-Bit Edge-Triggered D-Type Flip-Flops with 3-State Output
电源电压DC 4.50V min
输出接口数 8
输出电流 24.0 mA
电路数 1
通道数 16
位数 16
电压波节 5.00 V
输入电容 4.5 pF
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 48
封装 SSOP-48
长度 15.88 mm
宽度 7.49 mm
高度 2.59 mm
封装 SSOP-48
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
