74ACT11240NT

八路缓冲器/ 3态输出线路驱动器 OCTAL BUFFER/LINE DRIVER WITH 3-STATE OUTPUTS

description

This octal buffer or line driver is designed specifically to improve both the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. This device provides inverting outputs and symmetrical active-low output-enable OE inputs. This device features high fan-out and improved fan-in.

The 74ACT11240 is characterized for operation from −40°C to 85°C.

• Inputs Are TTL-Voltage Compatible

• Flow-Through Architecture Optimizes PCB Layout

• Center-Pin VCC and GND Configurations

   Minimize High-Speed Switching Noise

• EPIC™ Enhanced-Performance Implanted CMOS 1-μm Process

• 500-mA Typical Latch-Up Immunity at 125°C

• Package Options Include Plastic

   Small-Outline DW and Shrink

   Small-Outline DB Packages, and Standard

   Plastic 300-mil DIPs NT
