77061821P

Res Thick Film NET 820Ω 2% 0.8W ±100ppm/℃ BUS Conformal Coated 6Pin SIP Pin Thru-Hole Bulk

Downsize multiple resistors onto a single chip with the resistor array, developed by . This product"s 5 resistors have a value of 820 Ohm. This dependable part has a power rating of 0.8 W and a power rating per resistor of 0.15 W. Its temperature coefficient is ±100 ppm/°C. It has 6 terminals. This product comes packaged in bulk, so the parts will be stored loosely. This device utilizes thick film technology. It has a tolerance of 2%. This part has an operating temperature of -55 to 125 °C. This product"s terminal pitch is 2.54 mm. This product is 15.24 mm long, 4.95 mm tall and 2.5 mm deep. The 77061821P part has a pin termination style.
