77063221P

Res Cermet NET 220Ω 2% 4/5W ±100ppm/℃ ISOL Conformal 6Pin SIP Pin Thru-Hole Bulk

220 Ohm ±2% 100mW Power Per Element Isolated Resistor Network/Array ±100ppm/°C 6-SIP

得捷:
RES ARRAY 3 RES 220 OHM 6SIP

立创商城:
220Ω ±2%

贸泽:
Resistor Networks & Arrays 220ohms 6Pin 2% Isolated

艾睿:
Are you looking for a power-saving component that can be implemented in your circuit design? CTS brings you their 77063221P resistor array, essentially an IC chip with multiple resistors built in. Its temperature coefficient is ±100 ppm/°C. This dependable part has a power rating of 0.8 W and a power rating per resistor of 0.15 W. This product&s;s 3 resistors have a value of 220 Ohm. It has 6 terminals. This product comes packaged in bulk, so the parts will be stored loosely. The 77063221P part has a pin termination style. This product is 15.24 mm long, 4.95 mm tall and 2.5 mm deep. This part has an operating temperature of -55 to 125 °C. It has a tolerance of 2%. This device is made with thick film technology. This product&s;s terminal pitch is 2.54 mm.
