TE CONNECTIVITY / BUCHANAN 796949-7 接线端子块, PCB, 7路, 30-12AWG
7 POS TERMI-BLOK PCB MOUNT
Product Highlights
Connector
Connector Type = Wire Receptacle
Housing Color = Black
Not Side Stackable
Without Screw Flange
得捷:
TERM BLK 7P SIDE ENT 5.08MM PCB
e络盟:
接线端子块, PCB, 7路, 30-12AWG
艾睿:
Conn Eurostyle Block HDR 7 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact Box
安富利:
Conn Terminal Block 7 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact
Verical:
Conn Eurostyle Block HDR 7 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact Box
MASTER:
TERMINAL BLOCK PCB MOUNT W/INTERLOCK, 5.08mm PITCH
Powell:
Terminal Block Connectors
Online Components:
7 POS TERMI-BLOK PCB MOUNT
Electro Sonic:
7 POS TERMI-BLOK PCB MOUNT
触点数 7
线规 12AWG ~ 30AWG
触点电镀 Tin
额定电流 17.5 A
排数 1
电路数 7
易燃性等级 UL 94 V-0
针脚数 7
额定电流Max 17.5A/触头
工作温度Max 105 ℃
工作温度Min -40 ℃
额定电压Max 300 VAC
额定电压 300 V
工作电压Max 300 VAC
安装方式 Through Hole
高度 15.2 mm
外壳颜色 Black
颜色 Black
触点材质 Brass
工作温度 -40℃ ~ 105℃
外壳材质 Nylon 6/6
产品生命周期 Active
包装方式 Box
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
