749084-5

D-Sub标准连接器 RA SHLD PLUG HDR 50P

50 位 D 型 插头，公引脚

得捷:
CONN D-TYPE PLUG 50POS R/A SLDR

贸泽:
D-Sub标准连接器 RA SHLD PLUG HDR 50P

艾睿:
Devices such as printers and scanners that run the Small Computer System Interface standards and protocols will require this 749084-5 SCSI connector from 749084-5 in order to interface with each other. This PL connector&s;s 50 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. This connector has a single port. It has a maximum voltage rating of 30 VAC. Its pitch is 1.27 mm. It has a plug type gender. 749084-5 is housed in liquid crystal polymer. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its 50 terminals use the solder termination method. This SCSI connector has a minimum operating temperature of -55 °C and a maximum of 105 °C. This product is 52.45 mm long, 10.31 mm tall and 17.27 mm deep.

Chip1Stop:
Conn SCSI PL 50 POS 1.27mm Solder RA Thru-Hole 50 Terminal 1 Port

Verical:
Conn SCSI PL 50 POS 1.27mm Solder RA Thru-Hole 50 Terminal 1 Port

MASTER:
PLUG ASSEMBLY, SHIELDED, RIGHT ANGLE, AMPLIMITE .050 Series

Powell:
.050 Series Board Mount Connectors

Online Components:
PLUG ASSEMBLY, SHIELDED, RIGHT ANGLE, AMPLIMITE .050 Series

Electro Sonic:
50 50SR R/A PLUG ASSY
