796949-9

BUCHANAN - TE CONNECTIVITY 796949-9 Wire-To-Board Terminal Block, 5.08mm, 9Positions, 30AWG, 12AWG, 3mm², Screw

9 接线板 - 线至板 水平，带板 0.200"（5.08mm） 通孔

得捷:
TERM BLK 9P SIDE ENT 5.08MM PCB

贸泽:
Fixed Terminal Blocks PCB MOUNT 9 POSITION side angle

艾睿:
Never worry about wires becoming undone by implementing this eurostyle block 796949-9 PCB terminal block developed by TE Connectivity. It has a maximum voltage rating of 300 VAC. This is a 1-row connector. It has a straight body orientation. Its pitch is 5.08 mm. 796949-9 is housed in polyamide 6/6. This device has a maximum current rating of 17.5 A/contact. It uses the solder termination method. This quick disconnect terminal has an operating temperature of -40 to 105 °C. This product is 45.72 mm long, 15.2 mm tall and 9 mm deep. Its wire is 12-30 AWG.

安富利:
Conn Terminal Block 9 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact

Chip1Stop:
Conn Eurostyle Block 9 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact

Verical:
Conn Eurostyle Block HDR 9 POS 5.08mm Solder ST Thru-Hole 17.5A/Contact Box

MASTER:
TERMINAL BLOCK PCB MOUNT W/INTERLOCK, 5.08mm PITCH

Powell:
Terminal Block Connectors

Online Components:
9 POS TERMI-BLOK PCB MOUNT

Electro Sonic:
9 POS TERMI-BLOK PCB MOUNT
