74HCT1G86GW,125

74HCT 系列 5 V 表面贴装 单通道 2输入 异或门 - TSSOP-5

The 74HC595D is a high speed Si-gate CMOS device and is pin compatible with low power Schottky TTL LSTTL. They are specified in compliance with JEDEC standard No. 7A. The 74HC595D is an 8 stage serial shift register with a storage register and 3 state outputs. The registers have separate clocks. Data is shifted on the positive going transitions of the shift register clock input SHCP. The data in each register is transferred to the storage register on a positive going transition of the storage register clock input STCP. If both clocks are connected together, the shift register will always be one clock pulse ahead of the storage register. The shift register has a serial input DS and a serial standard output Q7S for cascading. It is also provided with asynchronous reset active LOW for all 8 shift register stages. The storage register has 8 parallel 3-state bus driver outputs. Data in the storage register appears at the output whenever the output enable input OE is LOW.

.

8 bit serial input

.

8 bit serial or parallel output

.

Storage register with 3 state outputs

.

Shift register with direct clear

.

100MHz typ. shift out frequency
