MURATA POWER SOLUTIONS 76602/1C 脉冲变压器, 1:1:1
2.06mH 通用 脉冲 1:1:1 通孔
得捷:
XFRMR 1:1:1 2060UH 17.5VUS C
e络盟:
脉冲变压器, 1:1:1
艾睿:
Easily capture rectangular electrical pulses of voltage changes in your circuit using this 76602/1C pulse transformer from Murata Power Solutions. This pulse transformer has a minimum operating temperature of 0 °C and a maximum of 70 °C. It has 6 terminals. The maximum DCR on the primary side is 1.5 Ohm. It also has a pulse transformer. It has a turn ratio of 1:1:1. This product is 12.7 mm long, 6.35 mm tall and 8.89 mm deep.
安富利:
Pulse Transformer 1:1:1 500VDC 1.5Ohm Prim. DCR 72pF 17.5Vus Through Hole
Chip1Stop:
Pulse Transformer 1:1:1 500VDC 1.5Ohm Prim. DCR 72pF 6Term. PC Pin Thru-Hole
Verical:
Pulse Transformer 1:1:1 500VDC 1.5Ohm Prim. DCR 72pF 6 Terminal PC Pin Thru-Hole
AMEYA360:
XFRMR 1:1:1 2060UH 17.5VUS C
Win Source:
XFRMR 1:1:1 2060UH 17.5VUS C
电容 35 pF
易燃性等级 UL 94 V-0
电感 2.06 mH
隔离电压 500 V
电阻DC) 1.5 Ω
工作温度Max 70 ℃
工作温度Min 0 ℃
安装方式 Through Hole
引脚数 6
封装 DIP
长度 12.7 mm
宽度 8.89 mm
高度 6.35 mm
封装 DIP
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tube
制造应用 电源管理, 工业, Industrial, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
