796638-7

可插拔接线端子 5.08MM RA HDR 7P

7 针位端子块 接头，公引脚，带罩（4 面） 0.200"（5.08mm） 90°，直角 - 通孔

得捷:
TERM BLOCK HDR 7POS 90DEG 5.08MM

贸泽:
可插拔接线端子 5.08MM RA HDR 7P

艾睿:
Protect your printed circuit boards from accidental damages with TE Connectivity&s;s shrouded 796638-7 header connector. This HDR connector&s;s 7 contacts that are made out of phosphor bronze and plated with tin. It has a right angle body orientation. It has a maximum voltage rating of 300 VAC. This is a 1-row connector. It has a header type gender. Its pitch is 5.08 mm. This device has a maximum current rating of 15 A/contact. This product is 37.38 mm long, 8.35 mm tall and 12 mm deep. It uses the solder termination method. 796638-7 is housed in green polyamide 6/6.

安富利:
Conn Shrouded Header HDR 7 POS 5.08mm Solder RA Thru-Hole

Chip1Stop:
Conn Shrouded Header HDR 7 POS 5.08mm Solder RA Thru-Hole

Verical:
Conn Shrouded Header 4 Sides HDR 7 POS 5.08mm Solder RA Thru-Hole

Newark:
# AMP - TE CONNECTIVITY  796638-7  7POS 5.08MM CE R/A HDR,TRM BLK New

MASTER:
TERMI-BLOK HEADER ASSEMBLY, 90 DEGREE, CLOSED ENDS, 5.08mm PITCH

Powell:
Eurostyle Terminal Blocks

Online Components:
7POS 5.08MM CE R/A HDR,TRM BLK

Electro Sonic:
7POS 5.08MM CE R/A HDR,TRM BLK
