Conn Shrouded Header HDR 24POS 2.54mm Solder RA Thru-Hole Tube
24 MTE HDR SRRA LTCH.100CL LF
得捷:
CONN HEADER R/A 24POS 2.54MM
艾睿:
Reduce safety concerns with this shrouded 7-104935-3 header connector from TE Connectivity which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 24 contacts that are made out of brass and plated with gold over nickel. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a right angle body orientation. This device has a maximum current rating of 3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. 7-104935-3 is housed in black thermoplastic. This connector has an operating temperature of -65 to 105 °C. This product is 63.5 mm long, 6.99 mm tall and 13.59 mm deep.
安富利:
Conn Shrouded Header HDR 24 POS 2.54mm Solder RA Thru-Hole Tube
Chip1Stop:
Conn Shrouded Header HDR 24 POS 2.54mm Solder RA Thru-Hole Tube
Verical:
Conn Shrouded Header 4 Sides HDR 24 POS 2.54mm Solder RA Side Entry Thru-Hole Tube
Newark:
# AMP - TE CONNECTIVITY 7-104935-3 24 MTE HDR SRRA LTCH.100CL LF New
MASTER:
HEADER ASSY, AMPMODU MTE, RIGHT ANGLE, SINGLE ROW, .100CL, .025 SQ POSTS
Powell:
.100 AMPMODU Headers, Housings & Contacts
Online Components:
24 MTE HDR SRRA LTCH.100CL LF
Electro Sonic:
24 MTE HDR SRRA LTCH.100CL LF
触点数 24
触点电镀 Tin
额定电流 3 A
绝缘电阻 5000 MΩ
排数 1
方向 Right Angle
易燃性等级 UL 94 V-0
针脚数 24
额定电流Max 3A/触头
工作温度Max 105 ℃
工作温度Min -65 ℃
接触电阻Max 15 mΩ
安装方式 Through Hole
高度 6.99 mm
外壳颜色 Black
颜色 Black
触点材质 Brass
工作温度 -65℃ ~ 105℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Tube
制造应用 汽车,通用,医疗,电信
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
