Connector Power Pin 4Position 4.14mm Solder Right Angle Through Hole 4 Terminal 1Port
04P MINI UMNL R/A HDR ASSY SN
Product Highlights
Header
Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
Number of Circuits = 4
4.14 x 4.14 mm Centerline, Matrix
Double-Row Contact Layout
得捷:
CONN HEADER R/A 4POS 4.14MM
立创商城:
770968-1
艾睿:
Use this 770968-1 power connector from TE Connectivity to power up your circuit without having to worry about energy seepage. This HDR connector&s;s 4 contacts that are made out of brass and plated with tin-lead over nickel. It has a header type gender. It has a right angle body orientation. This connector has a single port. Its pitch is 4.14 mm. It has a maximum voltage rating of 600 VAC. 770968-1 is housed in nylon. This device has a maximum current rating of 9.5 A/contact. This power connector has a minimum operating temperature of -20 °C and a maximum of 105 °C. This product is 12.7 mm long, 11.86 mm tall and 9.86 mm deep. Its 4 terminals use the solder termination method.
Jameco:
Connector Power Pin 4 Position 4.14mm Solder Right Angle Through Hole 4 Terminal 1 Port
安富利:
Conn Power PIN 4 POS 4.14mm Solder RA Thru-Hole 4 Terminal 1 Port
Verical:
Conn Power HDR 4 POS 4.14mm Solder RA Thru-Hole 4 Terminal 1 Port Bag
MASTER:
HEADER ASSEMBLY, RIGHT ANGLE, WITH SHORT PEG, 4 CIRCUIT, MINI UNIVERSAL MATE-N-LOKTM
Powell:
.163" Centerline, 600 V, 9.5 A max.
Online Components:
HEADER ASSEMBLY, RIGHT ANGLE, WITH SHORT PEG, 4 CIRCUIT, MINI UNIVERSAL MATE-N-LOKTM
Electro Sonic:
04P MINI UMNL R/A HDR ASSY SN
触点数 4
极性 Male
触点电镀 Tin Lead
额定电流 9.50 A
排数 2
方向 Right Angle
电路数 4
易燃性等级 UL 94 V-0
针脚数 4
安装角度 90.0 °
额定电流Max 9.5A/触头
工作温度Max 105 ℃
工作温度Min -20 ℃
额定电压Max 600 VAC
额定电压 600 VAC
安装方式 Through Hole
封装 -
引脚间距 4.14 mm
长度 9.86 mm
宽度 12.7 mm
高度 11.86 mm
封装 -
引脚间距 4.14 mm
外壳颜色 White
颜色 White
触点材质 Brass
工作温度 -20℃ ~ 105℃
外壳材质 Nylon
产品生命周期 Active
包装方式 Bag
制造应用 通用, Power
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ELV标准 Non-Compliant
ECCN代码 EAR99
HTS代码 8536694040
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
770968-1 TE Connectivity 泰科 | 当前型号 | 当前型号 |
1-770968-1 泰科 | 类似代替 | 770968-1和1-770968-1的区别 |
1-770968-0 泰科 | 类似代替 | 770968-1和1-770968-0的区别 |
