24VDC 2A 无锁存
General Purpose Relay DPDT 2 Form C Socketable
得捷:
RELAY GEN PURPOSE DPDT 2A 24VDC
立创商城:
24VDC 2A 无锁存
艾睿:
Signal Relay 24VDC 2A DPDT19x24x35.5mm Plug-In
Allied Electronics:
DPDT PCB Mount Non-Latching Relay Solder, 2 A, 24V dc
安富利:
Electromechanical Relay DPDT 2A 24VDC 890Ohm Plug-In
Chip1Stop:
Electromechanical Relay DPDT 2A 24VDC 890Ohm Plug-In
TME:
Relay: electromagnetic; DPDT; Ucoil:24VDC; 2A; miniature; 890Ω
Verical:
Electromechanical Relay 24VDC 890Ohm 2A DPDT 19x24x35.5mm Plug-In Signal Relay
Powell:
Communications/Signal PC Board Relays
Electro Sonic:
V23154C 721B104
触点电镀 Gold
额定电压DC 150 V
额定电压AC 125 V
额定电流 2 A
绝缘电阻 >1 MΩ
输入电压DC 24.0 V
触点额定电流 2 A
线圈电压 24 VDC
线圈电流 26.97 mA
线圈功率DC 650 mW
线圈电阻 890 Ω
额定电流Max 2 A
线圈电压DC 24 V
开关电流Max 2 A
工作温度Max 70 ℃
工作温度Min -40 ℃
额定电压 24 VDC
安装方式 Plug In, Solder
引脚数 10
封装 -
长度 19 mm
宽度 24 mm
高度 35.5 mm
封装 -
触点材质 Silver, Gold
工作温度 -40℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
