84137042图片1
84137042图片2
84137042图片3
84137042图片4
84137042图片5
84137042概述

Relay SSR 15mA 36V AC-IN 100A 280V AC-OUT 4Pin

The GN Series offers a group of robust and versatile general-purpose AC and DC Panel Mount relays.

These powerful single phase SSRs have superior thermal performance thanks to the use of DBC technology and are available in IP20 or IP00 protection degree packages.

These new generation solid state relays all feature anti-rotation barriers, flexible control voltage options, LED input status indicator, overvoltage protection on all AC output relays, and a wide range of power ratings to make your product selection easier.

* Current ratings from 10 to 125 amps

* Output voltage 24-280 and 48-660 VAC

* Direct bond copper substrate

* LED input status indicator

* Available with IP20 “touch-safe” cover

* Transient protection built-in

* UL508 Endurance Rating 10-50A

* UL/CSA/TUV Approved, CE Compliant to EN60950-1

84137042中文资料参数规格
技术参数

输出电流 100000 mA

输入电流 15 mA

隔离电压 4000 v

输出电压Max 280 V

输入电压 18VAC ~ 36VAC

封装参数

引脚数 4

封装 Hockey Puck

外形尺寸

封装 Hockey Puck

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买84137042
型号: 84137042
制造商: Crydom 快达
描述:Relay SSR 15mA 36V AC-IN 100A 280V AC-OUT 4Pin
