3A 至 9A,ON SemiconductorON Semiconductor 系列肖特基二极管可用于快速切换应用。### 标准Products with NSV-, SBR- or S-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.### 二极管和整流器,ON Semiconductor
肖特基势垒,3A 至 9A,
### 标准
带 NSV-、SBR- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
立创商城:
80SQ045NRLG
得捷:
DIODE SCHOTTKY 45V 8A AXIAL
欧时:
### 肖特基势垒二极管,3A 至 9A,ON SemiconductorON Semiconductor 系列肖特基二极管可用于快速切换应用。### 标准Products with NSV-, SBR- or S-prefixed Manufacturer Part Nos are AEC-Q101 automotive qualified.### 二极管和整流器,ON Semiconductor
贸泽:
Schottky Diodes & Rectifiers 8A 45V
e络盟:
肖特基整流二极管
艾睿:
Converting from AC to DC is simple when using a Schottky diode 80SQ045NRLG rectifier from ON Semiconductor. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This rectifier has a minimum operating temperature of -65 °C and a maximum of 125 °C. It is made in a single configuration. Its peak non-repetitive surge current is 140 A, while its maximum continuous forward current is 8 A.
Allied Electronics:
ON Semi 80SQ045NRLG; Schottky Diode; 45V 8A; 2-Pin DO-201AD
安富利:
Diode Schottky 45V 8A 2-Pin DO-201AD T/R
Chip1Stop:
Diode Schottky 45V 8A 2-Pin DO-201AD T/R
Verical:
Rectifier Diode Schottky 45V 8A 2-Pin DO-201AD T/R
Newark:
# ON SEMICONDUCTOR 80SQ045NRLG Schottky Rectifier, 45 V, 8 A, Single, DO-201AD, 2 Pins, 550 mV
罗切斯特:
Diode Schottky 45V 8A 2-Pin DO-201AD T/R
Win Source:
DIODE SCHOTTKY 45V 8A AXIAL
额定电压DC 45.0 V
额定电流 8.00 A
无卤素状态 Halogen Free
输出电流 ≤8.00 A
针脚数 2
正向电压 0.55 V
极性 Standard
热阻 50℃/W RθJA
正向电流 8 A
最大正向浪涌电流(Ifsm) 140 A
正向电压Max 550 mV
正向电流Max 8 A
工作温度Max 125 ℃
工作温度Min -65 ℃
安装方式 Through Hole
引脚数 2
封装 DO-201AD
长度 9.5 mm
宽度 5.3 mm
高度 9.5 mm
封装 DO-201AD
工作温度 -65℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Signal Processing, 工业, Automation & Process Control, Industrial, 自动化与过程控制, 信号处理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
80SQ045NRLG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
80SQ045NG 安森美 | 完全替代 | 80SQ045NRLG和80SQ045NG的区别 |
80SQ045N 安森美 | 类似代替 | 80SQ045NRLG和80SQ045N的区别 |
80SQ045NRL 安森美 | 类似代替 | 80SQ045NRLG和80SQ045NRL的区别 |
