双路4输入正与非门 DUAL 4-INPUT POSITIVE-NAND GATES
description/ordering information
The ’HC20 devices contain two independent 4-input NAND gates. They perform the Boolean function
Y = A •B•C •D or Y = A+ B+ C+ D in positive logic.
Wide Operating Voltage Range of 2 V to 6 V
Outputs Can Drive Up To 10 LSTTL Loads
Low Power Consumption, 20-µA Max ICC
Typical tpd = 11 ns
±4-mA Output Drive at 5 V
Low Input Current of 1 µA Max
艾睿:
Perform multiple different logical operations through the use of Texas Instruments&s; 84039012A logic gates. This gate has a minimum operating temperature of -55 °C and a maximum of 125 °C. This device comes in tube packaging. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
安富利:
NAND Gate 2-Element 4-IN CMOS 20-Pin LCCC Tube
Chip1Stop:
NAND Gate 2-Element 4-IN CMOS 20-Pin CLLCC Tube
Verical:
NAND Gate 2-Element 4-IN CMOS 20-Pin CLLCC Tube
罗切斯特:
NAND Gate 2-Element 4-IN CMOS 20-Pin CLLCC Tube
