826658-3

Conn Unshrouded Header HDR 6POS 2.54mm Solder ST Thru-Hole

3P AMPMODU II STIFT LEI

Product Highlights

Header

Header Type = Breakaway

Number of Rows = Dual

Number of Positions = 6

Mating Post Length = 8.08 mm

得捷:
CONN HEADER VERT 6POS 2.54MM

贸泽:
Headers & Wire Housings 3P AMPMODU II STIFT LEI

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded 826658-3 connector from TE Connectivity. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. This product is 15.24 mm long, 10.8 mm tall and 5 mm deep. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. 826658-3 is housed in green thermoplastic.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole

MASTER:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole Carton

Powell:
AMPMODU Unshrouded Headers

Online Components:
3P AMPMODU II STIFT LEI

Electro Sonic:
3P AMPMODU II STIFT LEI
