88.12.0.230.0002

FINDER  88.12.0.230.0002  模拟定时器, 插入式, 88系列, 多功能, 16 时间范围, 0.05 s, 100 h, 2转换继电器

可编程（多功能） 延时继电器 DPDT（2 Form C） 0.05 秒 ~ 100 小时 延时 8A @ 250VAC 可插

得捷:
RELAY TIME DELAY 100HR 8A 250V

欧时:
Series 88 Multi-function Plug-in TimerSupply Voltage 230Vac SPDT contact configuration Functions: on-delay, on-pulse, fixed pulse 0-5s delayed, symmetral recycling For use with 90 series sockets Type | 88.02 | 88.12 ---|---|--- Operating voltage: | 24-230Vac/dc | 24-230Vac/dc Output: | 2 RT | 2 RT Breaking capacity: | 8A/250Vac | 5A/250Vac Connection: | 11 pins | 8 pins Adjustment accuracy: | ± 3% of full scale |   Protection index:IP 40 |   |   Operating temperature: -10°C to +55°C |   |   ### 多功能

TME:
Timer; DPDT; 250VAC/5A; 24÷230VAC; 24÷230VDC; DIN; PIN:8

Newark:
# FINDER  88.12.0.230.0002  Analog Timer, Plug In, 88 Series, Multifunction, 16 Ranges, 0.05 s, 100 h, 2 Changeover Relays
