8LCM015P-301B-XX

MULTICOMP  8LCM015P-301B-XX  连接器, D sub, 堆叠式, 90deg D Sub Connectors系列, DA, 插头, 15 触点, 金属主体, 焊接

The is a 15-way 5A right angle D-subminiature Plug with gold over nickel plated brass contacts. This 8LC series black male D-subminiature connector has tin plated steel shell with grounding indents and PBT + glass-fibre reinforced UL94V-0 insulator.

.

15mR Maximum contact resistance

.

1000MR Minimum insulation resistance

.

1000VAC for one minute Minimum dielectric withstanding voltage

.

-55 to 105°C Operating temperature range
