2.54 mm IC 插座，引脚直径 0.76 mm瑞士 Preci-dip 插座连接器属于通孔和 SMD 安装类型。插座具有镀锡黄铜套管，带镀金铍铜（4 爪）触点夹 直角 SMD 安装属于曲柄引脚类型 直向 SMD 安装属于翼形类型 80*-**-***-**10-012***** 系列是薄型直向管座 ### 标准UL 94V-0### 集成电路引脚和插座条
2.54 mm IC ，引脚直径 0.76 mm
瑞士 Preci-dip 插座属于通孔和 SMD 安装类型。
插座具有镀锡黄铜套管，带镀金铍铜（4 爪）触点夹
直角 SMD 安装属于曲柄引脚类型
直向 SMD 安装属于翼形类型
80- .
- -**-***-**10-012***** 系列是薄型直向管座
### 标准
UL 94V-0
欧时:
### 2.54 mm IC 插座，引脚直径 0.76 mm瑞士 Preci-dip 插座连接器属于通孔和 SMD 安装类型。插座具有镀锡黄铜套管，带镀金铍铜（4 爪）触点夹 直角 SMD 安装属于曲柄引脚类型 直向 SMD 安装属于翼形类型 80*-**-***-**10-012***** 系列是薄型直向管座 ### 标准UL 94V-0### 集成电路引脚和插座条
得捷:
CONN SOCKET 20POS 0.1 GOLD PCB
立创商城:
2.54mm
e络盟:
板至板连接, 2.54 mm, 20 触点, 插座, 803 Series, 通孔安装, 2 排
艾睿:
Think of Precidip&s;s socket strip 803-87-020-10-001101 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This RCP connector&s;s 20 contacts that are made out of beryllium copper and plated with gold. It has a receptacle type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a maximum voltage rating of 150 VDC|100VAC. It has a straight body orientation. This device has a maximum current rating of 3 A. It uses the solder termination method. 803-87-020-10-001101 is housed in black polychlorinated terphenyl. This connector has an operating temperature of -55 to 125 °C. This product is 25.4 mm long, 7 mm tall and 5.08 mm deep.
安富利:
Conn Socket Strip RCP 20 POS 2.54mm Solder ST Thru-Hole Box
儒卓力:
**20P FEMALE HEADER 1R 2.54 THT **
