Conn Unshrouded Header HDR 100POS 2mm Solder ST Thru-Hole
100 位置 插座 0.079"(2.00mm) 通孔 镀金
得捷:
CONN RCPT 100POS 0.079 GOLD PCB
艾睿:
Mount this unshrouded 833-43-100-10-001000 header connector from Mill-Max Mfg. Corp. on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 100 contacts that are made out of beryllium copper alloy and plated with tin over nickel. It has a maximum voltage rating of 150 VDC|100VAC. Its pitch is 2 mm. It has a straight body orientation. This is a 1-row connector. It has a header type gender. It uses the solder termination method. 833-43-100-10-001000 is housed in black nylon 4/6. This product is 100 mm long, 7.89 mm tall and 4 mm deep.
Chip1Stop:
Conn Unshrouded Header HDR 100 POS 2mm Solder ST Thru-Hole
Verical:
Conn Socket Strip SKT 100 POS 2mm Solder ST Thru-Hole
触点数 100
触点电镀 Gold
额定电流 3 A
排数 2
针脚数 100
拔插次数 100
额定电流Max 3 A
工作温度Max 125 ℃
工作温度Min -55 ℃
接触电阻Max 10 mΩ
安装方式 Through Hole
封装 DIP
引脚间距 2.00 mm
长度 100 mm
宽度 4 mm
高度 4.19 mm
封装 DIP
引脚间距 2.00 mm
外壳颜色 Black
颜色 Black
触点材质 Beryllium Copper
工作温度 -55℃ ~ 125℃
外壳材质 Plastic
产品生命周期 Active
包装方式 Bulk
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
