87215-8

集管和线壳 UNSHRD VERT DUAL 24

针座 通孔 24 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 24POS 2.54MM

贸泽:
集管和线壳 UNSHRD VERT DUAL 24

艾睿:
TE Connectivity brings you their unshrouded 87215-8 header connector, an important safety tool for protecting your electronic components from accidental damage. This HDR connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a straight body orientation. This is a 2-row connector. It has a header type gender. This device has a maximum current rating of 3 A/contact. This product is 30.07 mm long, 10.36 mm tall and 4.87 mm deep. 87215-8 is housed in black thermoplastic. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 24 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header M 24 POS 2.54mm Solder ST Top Entry Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  87215-8  24 MODII HDR DRST UNSHRD .100 New

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL. VERTICAL, .025 SQUARE POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
24 MODII HDR DRST UNSHRD .100

Electro Sonic:
24 MODII HDR DRST UNSHRD .100
