87227-2

AMP FROM TE CONNECTIVITY  87227-2  板至板连接器, 针座, 4路, 2排

Standard Header Type, Thermoplastic Housing, 0.025 in. Post Size, Through Hole Header

** Housing** : Black thermoplastic, 94V-0 rated. ** Posts** : Copper alloy.

0.125 " termination post length

得捷:
CONN HEADER VERT 4POS 2.54MM

e络盟:
板至板连接器, 针座, 4路, 2排

艾睿:
Mounting this unshrouded 87227-2 header connector from TE Connectivity to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 4 contacts that are made out of copper alloy and plated with gold over nickel. It has a straight body orientation. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. 87227-2 is housed in black thermoplastic. This product is 4.67 mm long, 10.37 mm tall and 5.08 mm deep. This connector has an operating temperature of -65 to 105 °C.

Allied Electronics:
Header; Standard; PCB Mount; Dual; 4; 0.025 in.; 0.125 in.; 3 A

Jameco:
Connector Unshrouded Header HDR 4 Position 2.54mm Solder Straight Thru-Hole

安富利:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  87227-2  Board-To-Board Connector, 2.54 mm, 4 Contacts, Header, AMPMODU Mod II Series, Through Hole, 2 Rows

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL. VERTICAL, .025 SQUARE POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
04 MODII HDR DRST UNSHRD .100

Electro Sonic:
04 MODII HDR DRST UNSHRD .100

Win Source:
CONN HEADER VERT 4POS 2.54MM / Connector Header Through Hole 4 position 0.100" 2.54mm
