87230-5

AMPMODU 10 位置 通孔 双排 直角 0.100 英寸 针座

10 MODII HDR DRRA UNSHRD .100

Product Highlights

Header

Header Type = Standard

Number of Rows = Dual

Number of Positions = 10

Mating Post Length = 8.08 mm

得捷:
CONN HEADER R/A 10POS 2.54MM

立创商城:
2.54mm 方针

贸泽:
Headers & Wire Housings UNSHRD R.A. DUAL 10P

艾睿:
Mounting this unshrouded 87230-5 header connector from TE Connectivity to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 10 contacts that are made out of copper alloy and plated with gold over nickel. It has a header type gender. It has a right angle body orientation. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. 87230-5 is housed in black thermoplastic. This connector has an operating temperature of -65 to 105 °C. This product is 12.29 mm long, 6.04 mm tall and 15.42 mm deep. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole Package

Newark:
# AMP - TE CONNECTIVITY  87230-5  10 MODII HDR DRRA UNSHRD .100

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL RIGHT ANGLE, .025 SQ POSTS, SELECTIVELY LOADED

Powell:
.100 inch AMPMODU Headers

Online Components:
10 MODII HDR DRRA UNSHRD .100

Electro Sonic:
10 MODII HDR DRRA UNSHRD .100
