供电PLUS启用ICM的1x1 LED指示灯：绿 - 绿 PoE PLUS ENABLED ICM 1x1 LEDs: GREEN - GREEN
Magnetic Modular Jacks
Magnetic modular jacks, available in single- and multi-port versions, simplify customer board layouts by reducing the components required and support a wide variety of applications including computer, network and telecommunications equipment. Magnetic Modular Jacks incorporate wire-wound components magnetics in standard RJ45 jacks. These integrated magnetics, resistors and/or capacitors filter common-mode noise to provide signal integrity, protect PHY chips, provide DC isolation and offer low-mode conversion. Magnetic jacks are available in Power over Ethernet PoE versions that support PoE functionally while allowing customers to manage power. Magnetic modular jacks support Fast Ethernet 10/100 and Gigabit Ethernet applications.
Molex offers a range of Integrated Jacks or ICMs that provide a cost-effective, plug-and-play solution for customers implementing PoE and PoE Plus PoE+. Available in single port 1-by-1, 8-port 2-by-4, and 12-port 2-by-6 configurations and with LED options, the ICMs provide PoE+ Power Source Equipment PSE capability for a wide range of consumer applications.
Based on the RJ45 connector, the magnetic PDJack™ is the first integrated PD Power Device Jack in the market to combine PoE+ PD controller circuitry and bridge rectifiers with gigabit magnetics in one connector and provide a complete drop-in, single port solution. The PDJack™ simplifies PoE Plus implementation for any network device, reducing time-to-market, lowering costs and achieving considerable PCB space savings.
