8642AB

按钮开关, DPDT, 4A, 30VDC, 焊接

Single pole and double pole models with solder lug or pc terminals. Ratings up to 6 amps, UL option and numerous plunger, bushing, and accessory options. SPST, SPDT and DPDT pushbutton.

.

*

Features

* **Bushing 1⁄4 and 15⁄32**

* **UL Approved Models Available **

Specification

* **Max. Current/Voltage Rating with Resistive Load: 3 A 250 VAC — 6 A 125 VAC — 4 A 30 VDC**

* **Electrical Life at full Load: 30,000 Cycles**

* **Total Travel: 2.70MM 0.106**

* **Operating Temperture: –40°C to +85°C
