9055B BK005

ALPHA WIRE 9055B BK005 Coaxial Cable, Black, 20AWG, 0.52mm², Solid, 100Ft, 30.5m

The is a Coaxial Cable with solid silver-plated copper conductor and polyethylene insulation. The RG55B/U coaxial cable comes with a tinned copper braid shield 95% coverage and a black polyethylene jacket. This cable meets the requirements of military specifications and regulatory agencies such as UL and CSA standards.

.

17.3lbs Maximum pull tension

.

1400Vrms Voltage rating

.

28.8pf/ft at 1kHz Nominal ground capacitance

.

66% Velocity of propagation

.

10.1R/1000ft at 20°C Nominal conductor DC resistance DCR

.

2.5R/1000ft at 20°C Nominal OA shield DC resistance DCR

.

-55 to 80°C Temperature range
