Switch DIP N.O./N.C. SP8T 8 Knob 0.03A 30VDC Gull Wing 10000Cycles 2.54mm SMD Tube
Popular rotary encoded DIP switches are available to fit most form factor needs with standard and right-angle through-hole mounting plus surface mount versions as well. Octal, BCD and Hexadecimal are well represented. Optional keyed index knobs are available for the extended shafts in the series as well.
艾睿:
Switch DIP N.O./N.C. SP8T 8 Knob 0.03A 30VDC Gull Wing 10000Cycles 2.54mm SMD Tube
Allied Electronics:
Switch, DIP; 0.390 in. L x 0.380 in. W x 0.225 in. H; 8; 30 mA; 30 VDC; Rotary
安富利:
Switch DIP SP8T 8 Shaft 0.03A 30VDC Gull Wing 10000Cycle 2.54mm SMD Tube
额定电压DC 30.0 V
额定电流 100 mA
绝缘电阻 ≥5000 MΩ
针脚数 8
接触电阻 ≤50 MΩ
额定电流Max 0.03A @30VDC
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 30 VDC
额定电压DC Max 30 V
接触电阻Max 50 mΩ
安装方式 Surface Mount
长度 9.91 mm
宽度 9.65 mm
高度 5.08 mm
触点材质 Copper Alloy
材质 Plastic
工作温度 -40℃ ~ 85℃
产品生命周期 10000 Cycles
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
