Switch Limit N.O./N.C. SPDT Top Roller Plunger Cable 5A 250VAC 1/10HP 12.01N Linear Screw Mount
The CE switches are a rugged and versatile switch which can be applied indoors in harsh factory floor applications, as well as on outdoor equipment in extreme temperatures. A full range of actuators are available, including plain plungers, roller plungers, side rotary, multidirectional wire, and manually operated. The switches are also available with the industry standard, M12 miniature 4-pin connector. The MICRO SWITCH™ 914CE products meet UL and CSA standards, as well as European CE requirements.
艾睿:
The miniature 914CE2-15 limit switch, developed by Honeywell, can provide your project motion controlled data, as the switch itself is activated through movement or the presence of another object. It has a SPDT configuration. This device has a maximum current rating of 5 A @ 250VAC. 914CE2-15 is housed in zinc die cast. This limit switch has a minimum operating temperature of 0 °C and a maximum of 70 °C. The 914CE2-15 limit switch has a cable termination style. This product is 40.01 mm long, 67.01 mm tall and 16 mm deep. The maximum AC voltage rating is 250 VAC.
Allied Electronics:
IP66, IP67, IP68 Snap Action Limit Switch, Roller Plunger, Die Cast Zinc, NO/NC, 250V
Chip1Stop:
Switch Limit N.O./N.C. SPDT Top Roller Plunger Cable 5A 250VAC 1/10HP 12.01N Linear Screw Mount
Verical:
Switch Limit N.O./N.C. SPDT Top Roller Plunger Screw Mount 5A 250VAC 1/10HP 12.01N Linear Cable Automotive
MASTER:
Switch Limit N.O./N.C. SPDT Top Roller Plunger Cable 5A 250VAC 1/10HP 12.01N Linear Screw Mount
Electro Sonic:
Miniature Enclosed Switches Series 914CE: Top Roller Plunger; 1NC 1NO SPDT Snap Action; 15 foot Cable
