917783-1

2.5mm 信号双锁管座### 2.5mm TE Connectivity 信号双锁连接器

2.5mm 信号双锁管座

### 2.5mm 信号双锁

得捷:
CONN HEADER VERT 5POS 2.5MM

立创商城:
9177831

欧时:
TE Connectivity PCB 针座 Signal Double Lock 系列 5路 2.5mm节距 1排 直向 917783-1, 焊接端接, 3A, 通孔

贸泽:
Automotive Connectors 2.5 S.D.L POST HDR ASY 5P STD

艾睿:
Use this wire to board 917783-1 connector from TE Connectivity when board-to-board interconnects is required. This HDR connector&s;s 5 contacts that are made out of copper alloy and plated with pre-tin. This is a 1-row connector. Its pitch is 2.5 mm. It has a straight body orientation. It has a maximum voltage rating of 50 VDC|50VAC. It has a header type gender. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. This product is 15 mm long, 9.8 mm tall and 8.2 mm deep. This connector has an operating temperature of -30 to 105 °C. 917783-1 is housed in natural nylon 6/6.

安富利:
Conn Wire to Board HDR 5 POS 2.5mm Solder ST Thru-Hole Loose Piece

Verical:
Conn Wire to Board HDR 5 POS 2.5mm Solder ST Thru-Hole Bag/Box

MASTER:
2.5mm SIGNAL DBL-LOCK 5P POST HEADER ASS"Y

Powell:
2.5mm Signal Double Lock Connector

Online Components:
2.5 S.D.L POST HDR ASY 5P STD

Win Source:
5 Positions Header, Shrouded Connector 0.098" 2.50mm Through Hole Tin

Electro Sonic:
2.5 S.D.L POST HDR ASY 5P STD
