Res Conductive Plastic POT 10KΩ 20% 0.5W1/2W 1Elec/1MechTurn 6.35mm 31.75 X 15.88 X 17.46mm Pin Panel Mount/Through Hole
10k 欧姆 1 组 对数 面板安装 电位计 无 1 匝 导电塑料 0.5W，1/2W PC 引脚
得捷:
POT 10K OHM 1/2W PLASTIC LOG
Chip1Stop:
Res Conductive Plastic POT 10K Ohm 20% 0.5W1/2W 1Elec/1MechTurn 6.35mm 31.75 X 15.88 X 17.46mm Pin Panel Mount/Through Hole
Verical:
Res Conductive Plastic POT 10K Ohm 20% 0.5W1/2W 1Elec/1MechTurn 6.35mm 31.75 X 15.88 X 17.46mm Pin Panel Mount/Through Hole
Online Components:
Res Conductive Plastic POT 10K Ohm 20% 0.5W1/2W 1Elec/1MechTurn 6.35mm 31.75 X 15.88 X 17.46mm Pin Panel Mount/Through Hole
AMEYA360:
POT 10K OHM 5/8" SQ 1/4W PLAS
Electro Sonic:
Res Conductive Plastic POT 10K Ohm 20% 0.5W1/2W 1Elec/1MechTurn 6.35mm 31.75 X 15.88 X 17.46mm Pin Panel Mount/Through Hole
容差 ±20 %
额定功率 0.5 W
电阻 10 KΩ
阻值偏差 ±20 %
安装方式 Through Hole
封装 Square - 0.625" L x 0.625" W x 0.500" H 15.88mm x 15.88mm x 12.70mm
长度 31.75 mm
宽度 15.88 mm
高度 17.47 mm
封装 Square - 0.625" L x 0.625" W x 0.500" H 15.88mm x 15.88mm x 12.70mm
工作温度 -40℃ ~ 125℃
温度系数 ±1000 ppm/℃
产品生命周期 Obsolete
包装方式 Bulk
RoHS标准 Non-Compliant
含铅标准 Contains Lead
