908-43300

AMPHENOL RF  908-43300  射频/同轴连接器, MMCX同轴, 直角插头, 焊接, 50 ohm, RG188A/U, RG174/U, 黄铜

Micro-miniature coaxial interconnection. Incorporates industry accepted MMCX interface which allows for mating cohesion and provides a more robust interface than other unique proprietary interfaces.

.

*Frequency:** DC thru 6 GHz. **Impedance:** 50 Ohms. **Working Voltage at Sea Level:** ≤170 VRMS, 50 Hz. BeCu with gold plating. **Housing SMT:** Liquid crystal polymer. **Insulator:** PFTE. Conform to European CECC 22220 Spec.

得捷:
CONN MMCX PLUG R/A 50 OHM SOLDER

艾睿:
Conn MMCX 0Hz to 6GHz 50Ohm Solder RA Cable Mount PL Gold Automotive

Allied Electronics:
Connector; MMCX; Right Angle Plug; RG⁄ U; 50 Ohms; 6 GHz DC; 500 Megohms;

Jameco:
Connector MMCX PL 0Hz to 6GHz 50Ohm Solder Right Angle Cable Mount Gold

安富利:
Conn MMCX PL 0Hz to 6GHz 50Ohm Solder RA Cable Mount Gold

Chip1Stop:
Conn MMCX PL 0Hz to 6GHz 50Ohm Crimp RA Cable Mount Gold Automotive

Verical:
Conn MMCX 0Hz to 6GHz 50Ohm Solder RA Cable Mount PL Gold Automotive

Newark:
# AMPHENOL RF  908-43300  RF / Coaxial Connector, MMCX Coaxial, Right Angle Plug, Solder, 50 ohm, RG174, RG188, RG316, Brass

MASTER:
RF Connector MMCX Right Angle Crimp Plug for RG-174 RG-188A RG-316 50 Ohm

Powell:
MMCX Right Angle Crimp Plug for RG-174, RG-188A, RG-316, 50 Ohm

Online Components:
RF Connector MMCX Right Angle Crimp Plug for RG-174 RG-188A RG-316 50 Ohm

Electro Sonic:
RF Connector MMCX Right Angle Crimp Plug for RG-174 RG-188A RG-316 50 Ohm
