9-966140-6

AMP FROM TE CONNECTIVITY  9-966140-6  矩形电源连接器, Junior Power Timer系列, 通孔安装, 针座, 21 触点, 5 mm, 公

Connector Header position

得捷:
MESSERLEISTE 21P

立创商城:
9-966140-6

欧时:
MESSERLEISTE 21P

贸泽:
Automotive Connectors MESSERLEISTE 21P

艾睿:
This robust timer connector 9-966140-6 power connector from TE Connectivity easily retains normal operation in harsh and stressful environments. This HDR connector&s;s 21 contacts that are made out of phosphor bronze and plated with tin. Its pitch is 5 mm. This connector has a single port. It has a right angle body orientation. It has a header type gender. 9-966140-6 is housed in polyamide 6/6. This component comes in tray packaging, useful for fast picking and placing of your parts. This product is 25.7 mm tall. Its 21 terminals use the solder termination method.

Verical:
Conn Timer Connector HDR 21 POS 5mm Solder RA Thru-Hole 21 Terminal 1 Port Automotive Tray

Newark:
# AMP - TE CONNECTIVITY  9-966140-6  Rectangular Power Connector, Junior Power Timer Series, Through Hole, Header, 21 Contacts, 5 mm

MASTER:
TAB HEADER, 2.8x0.8, 6-21 POS. Messerleiste, 2.8x0.8, 6-21 pol.

Powell:
MESSERLEISTE 21P

Electro Sonic:
MESSERLEISTE 21P
