AMP FROM TE CONNECTIVITY 926886-1 触芯, Universal Mate-N-Lok系列, 公, 压接, 18 AWG, 镀锡触芯, Universal MATE-N-LOK Connectors
带印记 引脚 触点 锡 18-24 AWG 压接
得捷:
CONN PIN 18-24AWG CRIMP TIN
立创商城:
CONN PIN 18-24AWG CRIMP TIN 非整盘发货是100一截
贸泽:
管脚和插座连接器 SPLIT PIN 24-18 AWG
e络盟:
触芯, Universal MATE-N-LOK系列, 公, 压接, 18 AWG, 镀锡触芯, 通用MATE-N-LOK连接器
艾睿:
Easily improve a secured connection with this specially engineered 926886-1 connector contact from TE Connectivity. It has a straight body orientation. This device has a maximum current rating of 19 A. This has a Connector Power connector. This product comes in strip packaging to create faster automation between picking parts and placing them on circuit boards. It uses the crimp termination method. This product is 20.7 mm long, 3.5 mm tall and 3.4 mm deep. Its wire is 13-15 AWG.
安富利:
Contact PIN Crimp ST Cable Mount Strip
Verical:
Contact PIN Crimp ST Cable Mount Automotive Strip
Newark:
Contact, Universal Mate-N-Lok Series, Pin, 24 AWG, 18 AWG, Crimp, Brass
MASTER:
universal mnl stift dgb 0.2-0.8mm
Powell:
.250" Centerline, 600 V, 19 - 36 A max
Online Components:
UNIV.M-N-L.PIN
Electro Sonic:
UNIV.M-N-L.PIN
Win Source:
CONN PIN 18-24AWG CRIMP TIN / Pin Contact Tin 18-24 AWG Crimp Stamped
极性 Male
线规 18AWG ~ 24AWG
触点电镀 Tin
额定电压AC 600 V
额定电流 19 A
额定电流Max 19 A
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压Max 600 VAC
封装 -
高度 3.5 mm
封装 -
触点材质 Brass
材质 Brass
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 照明, 商业, 便携式器材, 电源供给, 消费电子产品, Power, HVAC
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
HTS代码 8538908040
