9833468Analog Positive Press Gauge Bottom Entry 10000psi, Connection Size 1/4 NPT
* 304 Stainless Steel Case with Vent Plug and SS Crimp Ring
* 316L SS Wetted Parts
* Lower Mount
* Polycarbonate Window
* Black Aluminum Pointer
* White Aluminum Dial with Black Lettering and Stop Pin
* Glycerine Filled
* Ambient Operating Temperature Glycerine Filled: –4°F to +140°F –20°C to +60°C
* Accuracy: ±2/1/2 of Span ASME B40.100 Grade A
**Applications:**
* High Dynamic Pressure Pulsations or Vibration
* Suitable for Corrosive Environments and Gaseous or Liquid Media That Will Not Obstruct the Pressure System
* Process Industry: Chemical/Petrochemical, Power Stations, Mining, On and Offshore, Environmental Technology, Mechanical Engineering and Plant Construction
Brand/Series 233.53 Series
Connecting Thread 1/4 NPT
Diameter 2.5 "
Fluid Type Gaseous, Liquid Media
Gauge Range 10000 PSI
Material 304 Stainless Steel Case, 316 Stainless Steel Wetted Part, Black Aluminum Pointer, Polycarbonate Window, Stainless Steel Polished Ring, White Aluminum Dial
Mounting Orientation Lower
Mounting Type Lower Mount
Type Analog
