NICHICON UVZ0J332MPD1TD 铝电解电容, 3300uF, 6.3V, 径向引线
By using pure aluminum foil in the anode, this electrolytic aluminum capacitor from can easily filter low frequencies. It can withstand a voltage of 6.3 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. The UVZ0J332MPD1TD aluminum electrolytic capacitor has a radial termination style. This product is 20 mm tall with a diameter of 10 mm. This part has a lead diameter of 0.6 mm and a pitch of 5 mm. Its capacitance value is 3300uF. It has a tolerance of 20%. Its leakage current is 623.7@1Min|207.9@2Min μA.
额定电压DC 6.3 V
电容 3300 µF
容差 ±20 %
纹波电流 840 mA
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Through Hole
引脚数 2
封装 剪切带
引脚间距 5 mm
长度 20 mm
高度 20 mm
直径 10.0 mm
封装 剪切带
引脚间距 5 mm
介质材料 Aluminum Electrolytic
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Cut Tape CT
寿命（小时） 1000h @105℃
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
UVZ0J332MPD1TD Nichicon 尼吉康 | 当前型号 | 当前型号 |
ECA-0JHG332 松下 | 功能相似 | UVZ0J332MPD1TD和ECA-0JHG332的区别 |
ECA-0JM332 松下 | 功能相似 | UVZ0J332MPD1TD和ECA-0JM332的区别 |
ECA-0JM332B 松下 | 功能相似 | UVZ0J332MPD1TD和ECA-0JM332B的区别 |
