NEUTRIK NC3MX 音频连接器, XLR, 3 触点, 插头, 电缆安装, 镀银触芯, 金属主体, X系列
X 系列 XLR 电缆托架
在方便、可重新密封的托盘上提供 XLR 连接器。
每包 25 个已拆卸的 XLR
### 注
25 件未组装连接器套件。
欧时:
Neutrik 3路 插头 电缆安装 XLR 连接器 NC3MX, 镀银触点, 50 V
e络盟:
XLR连接器, 3 触点, 插头, 电缆安装, 镀银触芯, 金属主体, X系列
艾睿:
Conn XLR Connector M 3 POS Solder ST Cable Mount 3 Terminal 1 Port
Allied Electronics:
3 Way Cable Mount XLR Connector, Male, Silver Plated Contacts, 50 V
Chip1Stop:
Conn XLR Connector M 3 POS Solder ST Cable Mount 3 Terminal 1 Port
TME:
Plug; XLR; male; PIN:3; straight; for cable; soldering; 3.5÷8mm; 16A
Verical:
Conn XLR Connector M 3 POS Solder ST Cable Mount 3 Terminal 1 Port
Newark:
# NEUTRIK NC3MX XLR Audio Connector, 3 Contacts, Plug, Cable Mount, Silver Plated Contacts, Metal Body, X Series
MASTER:
X Series - 3 pole male cable connector with Nickel housing and silver contacts. The "industry standard" XLR cable connector - easy to assemble with only 4 parts and no screws. Compact design with sturdy diecast shell - fibreglass reinforced hard pl
Electro Sonic:
X Series - 3 pole male cable connector with Nickel housing and silver contacts. The "industry standard" XLR cable connector - easy ...
触点数 3
极性 Male
触点电镀 Silver
额定电压DC 50.0 V
额定电压AC 50.0 V
额定电流 16 A
绝缘电阻 10000 MΩ
方向 Straight
针脚数 3
接触电阻 3.00 mΩ
拔插次数 1000
额定电流Max 16A/触头
工作温度Max 80 ℃
工作温度Min -30 ℃
额定电压Max 50 V
额定电压 50 V
接触电阻Max 3 mΩ
安装方式 Solder
引脚数 3
封装 Metal
长度 69 mm
封装 Metal
外壳颜色 Black
颜色 Nickel
触点材质 Brass
工作温度 -30℃ ~ 80℃
产品生命周期 Active
制造应用 Audio, 音频, 消费电子产品, Consumer Electronics
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
HTS代码 8536694020
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
NC3MX Neutrik | 当前型号 | 当前型号 |
NC3MX-BAG Neutrik | 完全替代 | NC3MX和NC3MX-BAG的区别 |
SVP555H Multicomp | 类似代替 | NC3MX和SVP555H的区别 |
SVP555H-BK Multicomp | 类似代替 | NC3MX和SVP555H-BK的区别 |
