4610X-102-470LF

BOURNS  4610X-102-470LF  电阻网络, 47R

5 - 隔离器

立创商城:
47Ω ±1Ω

得捷:
RES ARRAY 5 RES 47 OHM 10SIP

欧时:
### 5 - 隔离电阻器70°C 时功率 | 0.3W（单个），1.25W（总体） ---|--- 最大工作电压 | 100V 直流 尺寸（长 x 宽 x 高） | 25.35 x 2.49 x 5.08 mm 引线间距 | 2.54mm 电阻容差 | ±2 % 温度系数 | ±100 ppm/°C 温度系数记录 | ±50 ppm/°C 工作温度 | -55°C 至 +125°C ![http://china.rs-online.com/largeimages/L241721-01.gif]http://china.rs-online.com/largeimages/L241721-01.gif ### SIL 和 DIL 封装 - 已隔离

e络盟:
固定阵列电阻, 47 ohm, 4610X系列, 5 元件, 隔离, SIP, 10 引脚

艾睿:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W ±250ppm/°C ISOL Conformal Coated 10-Pin SIP Pin Thru-Hole Bulk

Allied Electronics:
Resistor, Thkfilm, Conf SIP, Rest 47 Ohms, 2%, 100V, 1.25W@70DegC, Isolated

安富利:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W ±250ppm/°C ISOL Conformal 10-Pin SIP Pin Thru-Hole Bulk

Chip1Stop:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W 250ppm/ C ISOL Conformal 10-Pin SIP Pin Thru-Hole Bulk

Verical:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W ±250ppm/C ISOL Conformal Coated 10-Pin SIP Pin Thru-Hole Bulk

Newark:
# BOURNS  4610X-102-470LF  Fixed Network Resistor, Isolated, 47 ohm, 100 V, 5 Elements, Isolated, SIP, 300 mW

MASTER:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W ±250ppm/°C ISOL Conformal Coated 10-Pin SIP Pin Thru-Hole Bulk

Electro Sonic:
Res Thick Film NET 47 Ohm 1 Ohm 1.25W ±250ppm/°C ISOL Conformal Coated 10-Pin SIP Pin Thru-Hole Bulk
