H811K8BYA

1kΩ 至 19.6kΩ轴向引线式精密 HOLCO 系列电阻器具有超高精度 - 低至 0.05% 高脉冲耐受 低电抗 低 TCR - 低至 5ppm/°C 长期稳定性 70°C 时高达 1W 匹配套件可提供 2ppm/°C ### Metal Film,HOLCO Axial ±0.1% 0.25W70°C 时功率 | 0.25W ---|--- 电阻容差 | ±0.1% 温度系数 | ±15ppm/°C 极限元件电压 | 200V 直流或交流有效值 工作温度 | \- 55°C → +155°C 尺寸 mm --- 主体长度 | 7.2 主体直径 | 2.5 引线长度 | 30 引线直径 | 0.6

1kΩ 至 19.6kΩ

轴向引线式精密 HOLCO 系列器具有超高精度 - 低至 0.05%

高脉冲耐受

低电抗

低 TCR - 低至 5ppm/°C

长期稳定性

70°C 时高达 1W

匹配套件可提供 2ppm/°C

### 金属膜，HOLCO 轴向 ±0.1% 0.25W

欧时:
HOLCO Axial resistor, 0.25W, 11K8

得捷:
RES 11.8K OHM 0.1% 1/4W AXIAL

立创商城:
金属膜电阻 11.8kΩ ±0.1% 250mW

e络盟:
The Holco H8 series are axial leaded precision metal film resistors that meet the requirement for economically priced components for industrial and military applications. The manufacturing facility utilises closely controlled production processes including the sputter coating of metal alloy films to ceramic substrates and laser spiralling to achieve close tolerance and high stability resistors. An epoxy coating is applied for environmental and mechanical protection.

艾睿:
Res Metal Film 11.8K Ohm 0.1% 0.25W1/4W ±15ppm/°C Conformal Coated AXL Bandoliered

安富利:
Res Metal Film 11.8K Ohm 0.1% 1/4W ±15ppm/°C Conformal AXL Thru-Hole Bandoliered
