3.00毫米（ 0.118 “ ）间距微飞度3.0 ™接头，表面安装，双排，直角，带压入金属固定夹， 2个电路 3.00mm .118" Pitch Micro-Fit 3.0™ Header, Surface Mount Compatible, Dual Row, Right Angle, with Press-fit Metal Retention Clip, 2 Circuits
针座 通孔，直角 2 位置 -
得捷:
CONN HEADER R/A 2POS
艾睿:
Safety is an important concern when designing electronic devices. Molex&s;s wire to board 0430450222 header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 2 contacts that are made out of brass alloy and plated with gold over nickel. It has a right angle body orientation. This is a 2-row connector. It has a header type gender. It has a maximum voltage rating of 600 V. This device has a maximum current rating of 5 A/contact. The component will be shipped in tray format. This connector has an operating temperature of -40 to 105 °C. 0430450222 is housed in black liquid crystal polymer. It uses the solder termination method. This product is 7.15 mm long, 8.77 mm tall and 12.2 mm deep.
安富利:
Conn Wire to Board HDR 2 POS 3mm Solder RA Thru-Hole Tray
Verical:
Conn Wire to Board HDR 2 POS 3mm Solder RA Side Entry Thru-Hole Micro-Fit 3.0™ Tray
