TDK NL453232T-820J-PF 表面贴装高频电感器, NL系列, 82 µH, ± 5%, 1812 [4532 公制], 8 MHz, 7 ohm
固定器
立创商城:
82uH ±5% 120mA
得捷:
FIXED IND 82UH 120MA 7 OHM SMD
贸泽:
Fixed Inductors 82uH
e络盟:
TDK NL453232T-820J-PF 表面贴装高频电感器, NL系列, 82 µH, ± 5%, 1812 [4532 公制], 8 MHz, 7 ohm
艾睿:
This rf chip NL453232T-820J-PF surface mount inductor from TDK is ideal for applications where space is a major influence of circuit design. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device is made with wirewound technology. It has a tolerance of 5%. It has an inductance of 82u H. This product is 4.8 mm long, 3.4 mm tall and 3.4 mm deep. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 8M Hz. This SMD inductor has a maximum DC current of 120m A with a maximum resistance of 7 Ohm.
安富利:
Ind RF Chip Unshielded Wirewound 82uH 5% 2.52MHz 50Q-Factor 120mA 1812 T/R
Verical:
Inductor RF Chip Unshielded Wirewound 82uH 5% 2.52MHz 50Q-Factor Ferrite 0.12A 7Ohm DCR 1812 T/R
Newark:
# TDK NL453232T-820J-PF Surface Mount High Frequency Inductor, NL Series, 82 H, 5%, 1812 [4532 Metric], 8 MHz, 7 ohm
Electro Sonic:
Inductor RF Chip Unshielded Wirewound 82uH 5% 2.52MHz 50Q-Factor Ferrite 120mA 7Ohm DCR 1812 T/R
额定电流 120 mA
容差 ±5 %
电感 82 µH
自谐频率 8 MHz
Q值 50.0
产品系列 NL
电感公差 ±5 %
测试频率 2.52 MHz
电阻DC) 7 Ω
额定电流DC 120 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±5 %
电阻DC Max 7 Ω
安装方式 Surface Mount
封装公制 4832
封装 1812
长度 4.5 mm
宽度 3.2 mm
高度 3.2 mm
封装公制 4832
封装 1812
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 500
制造应用 Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
NL453232T-820J-PF TDK 东电化 | 当前型号 | 当前型号 |
ELJ-FB820JF 松下 | 功能相似 | NL453232T-820J-PF和ELJ-FB820JF的区别 |
