NLCV32T-150K-EF

TDK  NLCV32T-150K-EF  表面贴装高频电感器, NLCV系列, 15 µH, ± 10%, 1210 [3225 公制], 26 MHz, 0.56 ohm

15 µH 无屏蔽 绕线 器 370 mA 728 毫欧最大 1210（3225 公制）

得捷:
FIXED IND 15UH 370MA 728MOHM SMD

立创商城:
15uH ±10% 560mΩ

欧时:
Wire Wound Ferrite Core 3.2 x 2.5mm 15uH

艾睿:
Use this power NLCV32T-150K-EF surface mount inductor from TDK to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 105 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This SMD inductor has a maximum DC current of 370m A with a maximum resistance of 728m Ohm. It has an inductance of 15u H. Its test frequency is 2.52M Hz, while its minimum self-resonant frequency is 26M Hz. This device is made with wirewound technology. It has a tolerance of 10%. This product is 3.4 mm long, 2.4 mm tall and 2.7 mm deep.

TME:
Inductor: wire; SMD; 1210; 15uH; 370mA; 0.56Ω; Q:15; ftest:2.52MHz

Verical:
Inductor Power Molded/Unshielded Wirewound 15uH 10% 2.52MHz 15Q-Factor Ferrite 0.37A 0.728Ohm DCR 1210 T/R

Newark:
# TDK  NLCV32T-150K-EF  Surface Mount High Frequency Inductor, NLCV Series, 15 H, 10%, 1210 [3225 Metric], 26 MHz
