MOLEX 501330-0400 线至板连接器, Pico-Clasp 501330系列, 4 触点, 插座, 1 mm, 压接, 1 排
单排 PicoClasp™
欧时:
Molex 连接器外壳 PICO-CLASP 系列 1mm节距 1行 4路 母 501330-0400
贸泽:
Headers & Wire Housings 1.0 WtB 4Ckt Female Housing Vert
Allied Electronics:
PICO-CLASP Series 1mm Pitch 4 Way 1 RowFemale Straight PCB Housing 501330
安富利:
Conn Housing RCP 4 POS 1mm Crimp ST Bag
Chip1Stop:
Conn Housing F 4 POS 1mm Crimp ST Cable Mount Pico-Clasp™ Bag
Newark:
# MOLEX 501330-0400 Wire-To-Board Connector, 1 mm, 4 Contacts, Receptacle, Pico-Clasp 501330 Series, Crimp, 1 Rows
MASTER:
Conn Housing F 4 POS 1mm Crimp ST Cable Mount Pico-Clasp™ Bag
Electro Sonic:
Conn Housing F 4 POS 1mm Crimp ST Cable Mount Pico-Clasp™ Bag
触点数 4
极性 Female
额定电流 1 A
排数 1
灼热丝测试标准 Non-Compliant
无卤素状态 Low Halogen
针脚数 4
额定电流Max 1A/触头
额定电压Max 50 V
封装 插座
长度 5.7 mm
宽度 2.94 mm
封装 插座
触点材质 Phosphor Bronze
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Bulk
制造应用 计算机和计算机周边, Computers & Computer Peripherals, Consumer Electronics, 消费电子产品
RoHS标准 RoHS Compliant
含铅标准 Lead Free
