5-104652-8

板对板与夹层连接器 80 POS SMT RECPT VERT DUAL ROW

80 Position Receptacle Connector Surface Mount

得捷:
CONN RCPT 80POS 0.05 GOLD SMD

贸泽:
板对板与夹层连接器 80 POS SMT RECPT VERT DUAL ROW

艾睿:
Use this socket strip 5-104652-8 header connector from TE Connectivity where IDC ribbon cables are used. This RCP connector&s;s 80 contacts that are made out of copper alloy and plated with gold over nickel. It has a receptacle type gender. Its pitch is 1.27 mm. It has a straight body orientation. This is a 2-row connector. It has a maximum voltage rating of 30 VAC. This device has a maximum current rating of 4 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. 5-104652-8 is housed in black thermoplastic. This connector has an operating temperature of -65 to 105 °C. This product is 55.27 mm long, 4.83 mm tall and 4.47 mm deep. It uses the solder termination method.

安富利:
Conn Socket Strip RCP 80 POS 1.27mm Solder ST SMD Tube

Chip1Stop:
Conn Socket Strip RCP 80 POS 1.27mm Solder ST SMD Tube

Verical:
Conn Socket Strip RCP 80 POS 1.27mm Solder ST SMD Box/Tube

Newark:
# AMP - TE CONNECTIVITY  5-104652-8  80 50/50 GRID DRST SFMNT RCPT New

MASTER:
ASSEMBLY, RECEPTACLE, VERTICAL,DOUBLE ROW, SURFACE MOUNT,AMPMODU 50/50 GRID CONNECTOR

Powell:
.050 Inch AMPMODU 50/50 Grid

Electro Sonic:
80 50/50 GRID DRST SFMNT RCPT
