5175474-6

Conn SCSI F 50POS 1.27mm Solder RA Thru-Hole 50 Terminal 1Port Tray

50 位置 插座 连接器 板至板，高密度 通孔，直角 焊接

得捷:
CONN BTB HD RCPT 50POS R/A SLDR

贸泽:
I/O Connectors R.A. RECPT 50P Series I standard

艾睿:
Devices such as printers and scanners that run the Small Computer System Interface standards and protocols will require this 5175474-6 SCSI connector from 5175474-6 in order to interface with each other. This F connector&s;s 50 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. Its pitch is 1.27 mm. It has a maximum voltage rating of 250 VAC. This connector has a single port. It has a female type gender. 5175474-6 is housed in nylon 6/6. This device has a maximum current rating of 1 A/contact. This component will be shipped in tray format. This SCSI connector has a minimum operating temperature of -55 °C and a maximum of 85 °C. Its 50 terminals use the solder termination method. This product is 41.68 mm long, 7.5 mm tall and 17.46 mm deep.

Allied Electronics:
CHAMP 050 Series 2.54mm Pitch 50 Way 2 Row Female Right Angle PCB Conn Housing

Verical:
Conn High Density F 50 POS 1.27mm Solder RA Thru-Hole 50 Terminal 1 Port Tray

Electro Sonic:
CHAMP 050 B/B REC H W/LEG 50P
