5558343-1

AMP FROM TE CONNECTIVITY  5558343-1  模制连接器, RJ45

模块化 - 插孔 8p8c（RJ45，以太网） 90°角（直角） 无屏蔽 Cat5

得捷:
CONN MOD JACK 8P8C R/A UNSHLD

e络盟:
模制连接器, RJ45

艾睿:
Do not worry about a bad telecom line connection again with this rj-45 5558343-1 telephone and telecom connector manufactured from TE Connectivity. This F connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. This connector has a single port. It has a female type gender. It has a maximum voltage rating of 150 VAC. Its pitch is 2.54 mm. It has a right angle body orientation. This device has a maximum current rating of 1.5 A/contact. This component will be shipped in tray format. It uses the solder termination method. This part has an operating temperature of -40 to 80 °C. This product is 15.11 mm long, 13.39 mm tall and 20.57 mm deep. 5558343-1 is housed in black nylon.

Allied Electronics:
Cat5e RJ45 Connector Socket, Unshielded, Right Angle, Panel Mount 5558343

安富利:
Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Tray Cat 5e

TME:
Socket; RJ45; PIN:8; Cat:5e; low profile; Pin layout:8p8c; THT

Verical:
Conn RJ-45 F 8 POS 1.02mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 5e Tray

Newark:
# AMP - TE CONNECTIVITY  5558343-1  Modular Connector, Cat5e, RJ45, Jack, 8 Contacts, 8 Positions, 1 Ports

MASTER:
MODULAR JACK ASSEMBLY, 8 POSITION, RIGHT ANGLE, LOW PROFILE, CATEGORY 5, WITH PANEL STOPS

Powell:
PCB Mounted Jacks - Single Port, Multi-port and Stacked

Online Components:
MJ,8POS,R/A,CAT5,PNL STOP

Electro Sonic:
MJ,8POS,R/A,CAT 5e,PNL STOP
