5745413-1概述

AMP FROM TE CONNECTIVITY  5745413-1  连接器, 标准D-SUB

Designed specifically for the truck, bus, and off-highway industry, the HDP20 Series are heavy duty, environmentally sealed, multi-pin circular connectors. Available in metal or thermoplastic housings, these connectors offer multiple pin configurations that accept contact sizes 4 through 20. The HDP20 Series shells are thermoplastic. Both feature quick connect-disconnect bayonet coupling, single hole bulkhead mounting, silicone seals, and a rear insertion/rear removal contact system

The HDP20 Series is a heavy duty rated, environmentally sealed, composite shell, multi-pin connector. The composite thermoplastic shell is ideal in applications where chemicals can damage a connector housing. HDP20 features quick connect-disconnect bayonet coupling, single hole bulkhead mounting, silicone seals, and a rear insertion/rear removal contact system.

* * *

5745413-1中文资料参数规格
技术参数

触点数 37

极性 Male

触点电镀 Gold, Tin over Nickel

排数 2

方向 Vertical

易燃性等级 UL 94 V-0

针脚数 37

工作温度Max 105 ℃

工作温度Min -55 ℃

额定电压 250 VAC

工作电压Max 250VDC, 250VAC

封装参数

安装方式 Through Hole

引脚间距 2.77 mm

外形尺寸

长度 69.31 mm

宽度 12.54 mm

高度 17.5 mm

引脚间距 2.77 mm

物理参数

外壳颜色 Black

颜色 Black

触点材质 Brass

工作温度 -55℃ ~ 105℃

外壳材质 Thermoplastic

其他

产品生命周期 Active

包装方式 Tube

制造应用 Signal

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

ELV标准 Compliant

海关信息

ECCN代码 EAR99

HTS代码 8536694040

数据手册

在线购买5745413-1
型号: 5745413-1
制造商: TE Connectivity 泰科
描述:AMP FROM TE CONNECTIVITY  5745413-1  连接器, 标准D-SUB
替代型号5745413-1
型号/品牌 代替类型 替代型号对比

5745413-1

TE Connectivity 泰科

当前型号

当前型号

745413-1

泰科

功能相似

5745413-1和745413-1的区别

SPC15413

Multicomp

功能相似

5745413-1和SPC15413的区别

SPC15275

Multicomp

功能相似

5745413-1和SPC15275的区别
